Newsletter - New Application Note: Daisy-Chain Board Synchronization


​​​​ In this application note, we describe how to use our daisy-chain feature on ADQ8 to distribute and calibrate the trigger signal in large multi-channel systems. The method can be used to achieve 200 picosecond timing alignment across multiple chassis. Learn about:

  • Daisy-chaining the trigger signal
  • Calculating rearm time
  • Replacing a device in an installed system
  • Performing calibration
