ADQ32 NOW SUPPORTS UP TO 5 GS/s!
Increased sampling rate, improved clocking flexibility, firmware
development kit, and programmable noise reduction – the recent ADQ32
upgrade offers significant improvements!
ADQ32 is a fourth-generation 12-bit digitizer with an open
field-programmable gate array (FPGA). It is optimized for OEM integration
in the most computationally demanding applications and provides built-in
peer-to-peer streaming to graphics processing units (GPU) at 7 Gbyte/s.
The latest upgrade contains several added features that are included free
of charge:
| Original Feature | Additional Feature Now Available |
|---|
| Dual-channel operation at 2.5 GS/S sampling rate | Single-channel operation at 5 GS/s sampling rate |
| Fixed sampling frequency | Variable sampling frequency |
| Fixed external clock reference frequency | Variable external clock reference frequency |
| Firmware development kit released |
| Programmable FIR filter for noise reduction |
Free Upgrade for Existing Customers
Existing ADQ32 customers can claim their free upgrade to benefit from
these new features. The upgrade is quick and can easily be done by the
customer with provided firmware and existing software. Please contact your
local sales representative using the button below.
Customizations for OEM Customers
ADQ32 is based on a flexible architecture that can easily be customized
for OEM customers. Possible modifications include analog front-end
modifications, additional sampling rate options, custom input voltage
range, extended analog input bandwidth, alternative form factors, custom
firmware and software, and more. OEM customers are welcome to contact us
for further discussions.
